Factory direct sell plastic pallet with three runners, racking pallet

Short Description:

1.Silk screen printing allow;

2.Open hole design panel type with grid surface;

3.Bottom type 3 runners type;

4.Reinforced ribs type;

5.Production process One time injection molding ;

6.Usage for Warehouse, Racking,transport etc;

7.Operating temperature -20℃~60℃;

Send email to us

Product Detail

Product Tags

Product Description

(1). Injection molding molding, single-face grid design, four sides into the fork, convenient for manual extraction, high operation efficiency.

(2) .The bottom reinforcement, fork reinforcement thickening design, impact resistance is stronger.

(3). Using high density polyethylene HDPE raw materials, non-toxic not water-absorption, moisture-proof not mildew, corruption and pest resistance, no nail thorn not dandruff, can be recycled.

(4). The section of the product bearing surface is the "T" tendon structure, which increases the carrying capacity of the bearing surface. The "T" panel will not produce extrusion marks on the packaging, which is conducive to protecting the product packaging.

(5). Fine workmanship, smooth surface without burr, strong and strong.

(6). Not easy to collapse and deformation, more solid, product stability, load-bearing, cold resistance and heat resistance.

Product Parameters

1.The Basic Product Parameter Table:

Product size	1200mm1000mm150mm
Product load	5.0 tons dynamic		load: 1tons
Material	High density polyethylene (HDPE)
Into the fork way	all sides into the fork
Product color	blue (can be customized according to customer requirements)
Identification process	template making board
	Silk screen printing
Structure and process	Panel type			The grid plane
	At the bottom of the type			3runners
	pallet:	facial		Grid surface design Stack goods against moisture
		At the bottom of the		3 kdis buttom design reinforced rid
	The production process	Encrypto-type tensile reinforcement
Operating temperature	-20℃~60℃

Product Size Parameters

XFW1210-150

XFW1210-160

Product Superiority

(1). Trlet panel T-tendon structure, enhance the tension between the tendon on the pallet surface, and increase the pallet intensity;

(2). three ranner bottom foot design, four sides enter the fork, suitable for a variety of forklifts ;

(3).The bottom of the intensive tensile, impact resistance, not easy to deformation, stronger and more stable load.

(4) The pallet face is designed with anti-slip block, which is used for anti-slip requirements of goods storage.

(5). The bottom of the pallet is designed with anti-slip block, which is used for the anti-slip requirements of the pallet on the shelf.

(6). The contact surface between fork and pallet is designed with anti-slip block to ensure the safety of the use of four-way forward fork and goods.

Applicable Industries

Pallet is suitable for logistics storage, food, printing, supermarket, pharmaceutical, chemical and other industries, and is widely used.

wahaha

Heaven and earth

Shenzhen salt

Tomson Biken

Product Quality Standard

(1) Appearance:
The surface of the pallet is flat, no flash, no cracks and deformations that affect the use, no burrs on the edges, and smooth gates.
(2) Color:
There is no obvious color difference on a single pallet, and the color of the same batch of products is basically the same.
(3) Inspection standard:
Refer to GB/T 15234-1994 "Plastic Flat Pallets", the requirements other than the standard shall be agreed by both parties

ODM

We also have ODM service, if none of the size above is suitable for you, we also can make for you a new design according to your drawing or sample or your requirement.
Please just send to us your inquiry,we can help you from 0 to 100.
From a photo to become a products, and organize for you the transportation and shipping, from our factory to your hand.
Just feel free to contact with us for more.
